How Does the Ledsreact Pro Work? A Technical Deep Dive

The Ledsreact Pro represents a breakthrough in sports performance testing through its innovative combination of radar technology, real-time processing, and cloud-based analytics. Let's examine how this comprehensive system operates from hardware to cloud infrastructure.

Hardware Technology

Revolutionary Radar System

At its core, the Ledsreact Pro utilizes radar technology to track player movements with high precision. Read more about what radar is here.

The system can:

• Detect movements within a 40-meter range (and beyond!)

• Track multiple athletes simultaneously

• Measure linear and multidirectional movements with high precision

• Operate without requiring athletes to wear any devices


Visualization of the raw radar data on the x and y axis (can you guess which drill this is?)

Integrated LED Interface

The device features an intelligent LED system that:

• Provides visual cues for test initiation and completion

• Displays directional signals for complex movement patterns

• Offers real-time feedback through color-coded responses

• Ensures precise timing through synchronized audio-visual signals


Visualization of the Ledsreact Pro for agility & performance measuring

Mobile Application

Coaches use the mobile application on their smartphone or tablet to start/stop tests on the device.

The mobile app provides:

• Real-time test control and monitoring

• Nearly instant results (of total time per player)

• Player and team management

• Custom test protocol creation

• Custom lists of tests


 Available on the iOS Apple store here.

 Available on the Google Play store here.

Performance Data Processing

If the Pro has WiFi connection, it will upload the movement data instantly after each player completed their exercise bout.

From mobile app v3.2.0 and firmware 3.5.0 onwards, it’s possible for the device to upload the data via Bluetooth connection with your mobile device. An LTE connection in the field is enough.

As soon as the radar data is uploaded, we filter and analyze it to extract the following metrics:

• Split times

• Speed (peak and average velocities, as well as the speed at every moment)

• Acceleration and deceleration metrics

• Force-velocity power (FVP) profiling (for sprints of at least 20 meters)

• F0 (Theoretical Maximal Horizontal Force)

• v0 (Theoretical Maximum Velocity)

• Pmax (Maximal Power Output)

• FV Slope

• RFmax (Theoretical Maximal Ratio of Force)

• DRF (Decrease in Ratio of Force)

• Horizontal power output

The data is stored in our cloud platform and is securely encrypted at rest.

Visualization in our web platform

The comprehensive web interface enables:

• Detailed performance analysis

• Historical data comparison

• Comparison between players

• Team and player management

• CSV exports

• (coming soon) video analysis overlays


Visualization of speed during a T-test

​

Data export and API access

Our web platform provides the option to export all data as CSV.

For the technically savvy user, we can provide API keys and documentation at request, for programmatic access to their club’s data.

Security and Data Management

Data Protection

The platform implements robust security measures:

• End-to-end encryption for data transmission

• Secure authentication and authorization

• Role-based access control

• Regular security audits

Data Governance

The system ensures data integrity through:

• Automated validation checks

• Data versioning and backup

• Audit trail maintenance

• Compliance with sports industry standards

Read our article on Ledsreact data security and privacy practices here, for more details.

Comparison to other technologies

Compared to other technologies used in sports training, the Ledsreact Pro offers several advantages:

1. Accuracy: Radar provides highly precise measurements of distance and speed, surpassing many optical systems.

2. Time-saving: No need to set up timegates, configure different wearables or other complicated tech... Just press "Play"

3. All-weather capability: Unlike some camera-based systems, radar works effectively in various lighting conditions and weather situations.

4. Real-time tracking: Radar allows for instantaneous tracking, enabling the Ledsreact Pro to provide immediate feedback and adapt drills on the fly.

5. Non-invasive and wearable-free: Athletes don't need to wear any special equipment or markers, allowing for natural, unrestricted movement.

While other technologies like optical motion capture or GPS tracking have their place in sports analysis, the Ledsreact Pro's radar-based system offers a unique combination of accuracy, responsiveness, and ease of use. This makes it particularly well-suited for agility training and reactive drills, where split-second timing and precise movement tracking are crucial.

The Ledsreact Pro's innovative use of radar technology, combined with its programmable LED signals and customizable drills, creates a powerful tool for athletes and coaches looking to enhance performance in sports where quick reactions and agility are key.

Practical Applications

The Ledsreact Pro's comprehensive system enables:

• Rapid team-wide testing (30+ athletes in under 3 minutes)

• Precise return-to-play (RTP) monitoring

• Evidence-based performance optimization

• Objective talent identification and development

This integrated approach to performance testing represents a significant advancement in sports technology, providing coaches and practitioners with precise, actionable data without the constraints of traditional wearable systems.

The combination of advanced radar technology, real-time processing, and comprehensive analytics makes the Ledsreact Pro an invaluable tool for elite sports performance departments focused on gaining competitive advantages through data-driven decision making.
